Room thermostat RT 01 D-230 (230 V) | 86018
Room thermostats RT 01 for controller terminal bar WB 01/WB 10 D
in-stock items
- compact, modern design
- easy surface mounting or mounting to standard in-wall switch boxes
- either as 230 V or as battery version
- suitable for heating and cooling
Determination of the actual ambient temperature and adjustment of the reference value for the room temperature. Can also be used for cooling (manual switching).
The room thermostat RT 01 is a part of the complete system FloorControl for single-room temperature control. Each room thermostat measures the actual ambient temperature and switches the output to obtain the required reference temperature. The reference value for the room temperature is adjusted by means of the keys. The integrated display shows the values. The actual temperature in rooms with an underfloor heating system is compared to the reference temperature on an ongoing basis.
Versions:
RT 01 D-BAT: Version with battery, suitable for wall mounting
RT 01 D-230: 230 V version, suitable for mounting to standard junction boxes/in-wall switch boxes
- Operating temperature range
- Ambient:
- 5/50 °C
- Storage:
- 5/50 °C
- Temperature adjustment range
- 5/35 °C
- Accuracy:
- ± 0.5 K
- Supply voltage
- RT 01 D-230: AC 230 V
- RT 01 D-230:
- RT 01 D-230: 5.396 VA
- Contact rating
- NC:
- max. AC 250 V, 1 A
- NO:
- max. AC 250 V, 1 A
- Housing
- plastic (PC/ABS)
- Colour:
- white (RAL 9003)
- Degree of protection:
- IP 20 (EN 60529)
- Weight
- RT 01 D-230: 105 g
- Compatibility
- RT 01 D-230: WB 01 D-8-230
