Thermometers THK With capillary tube

AFRISO Thermometer mit Kapillarleitung THK 52 0/120C 500mm D2105 VOR 91340 91350 91360 91370 AFRISO Thermometer mit Kapillarleitung THK 52 0/120C 500mm D2105 VOR 91340 91350 91360 91370
Thermometer mit Kapillarleitung THK 52 0/120C 500mm D2105
AFRISO Thermometer mit Kapillarleitung THK 52 0/120C 500mm D2105 VOR 91340 91350 91360 91370
AFRISO Thermometer mit Kapillarleitung THK 58 S Cu 0/120C 1000mm D2115 SAR 90950 90960 90970 90980 AFRISO Thermometer mit Kapillarleitung THK 58 S Cu 0/120C 1000mm D2115 SAR 90950 90960 90970 90980
Thermometer mit Kapillarleitung THK 58 S Cu 0/120C 1000mm D2115
AFRISO Thermometer mit Kapillarleitung THK 58 S Cu 0/120C 1000mm D2115 SAR 90950 90960 90970 90980
 BEF 91160 91170 91180 91190  BEF 91160 91170 91180 91190
 BEF 91160 91170 91180 91190 <div class="gallery-information"> <p> <strong>Type THK 37</strong> </p> <p>Dimensions (in mm)</p> <b>Legende:</b> <ol> <li>Capillary length</li> </ol> </div>
 BEF 91220 91230 91240 91250  BEF 91220 91230 91240 91250
 BEF 91220 91230 91240 91250 <div class="gallery-information"> <p> <strong>Type THK 40</strong> </p> <p>Dimensions (in mm)</p> <b>Legende:</b> <ol> <li>Capillary length</li> </ol> </div>
 BEF 91280 91290 91300 91310  BEF 91280 91290 91300 91310
 BEF 91280 91290 91300 91310 <div class="gallery-information"> <p> <strong>Type THK 45</strong> </p> <p>Dimensions (in mm)</p> <b>Legende:</b> <ol> <li>Capillary length</li> </ol> </div>
AFRISO Thermometer mit Kapillarleitung THK 52 0/120C 500mm D2105 BEF 91340 91350 91360 91370 AFRISO Thermometer mit Kapillarleitung THK 52 0/120C 500mm D2105 BEF 91340 91350 91360 91370
Thermometer mit Kapillarleitung THK 52 0/120C 500mm D2105
AFRISO Thermometer mit Kapillarleitung THK 52 0/120C 500mm D2105 BEF 91340 91350 91360 91370 <div class="gallery-information"> <p> <strong>Type THK 52</strong> </p> <p>Dimensions (in mm)</p> <b>Legende:</b> <ol> <li>Capillary length</li> </ol> </div>
 91280 91290 91300 91310 object_image_56080imagemain_en
 VOR 91160 91170 91180 91190
 VOR 91220 91230 91240 91250
AFRISO Thermometer mit Kapillarleitung THK 52 0/120C 500mm D2105 VOR 91340 91350 91360 91370
 SAL 91280 91290 91300 91310
AFRISO Thermometer mit Kapillarleitung THK 58 S Cu 0/120C 1000mm D2115 SAR 90950 90960 90970 90980
 BEF 91160 91170 91180 91190
 BEF 91220 91230 91240 91250
 BEF 91280 91290 91300 91310
AFRISO Thermometer mit Kapillarleitung THK 52 0/120C 500mm D2105 BEF 91340 91350 91360 91370
Data sheet Thermometers THK With capillary tube
AFRISO Data sheet Thermometers THK With capillary tube

Versions

Nominal size Housing Push on bezel Pointer Dial Scale Range Capillary length Type Part no. Remember
37 mm Grey Black White Black 0/120 °C 500 mm THK 37 67512105
37 mm Grey Black White Black 0/120 °C 1,000 mm THK 37 67512115
37 mm Grey Black White Black 0/120 °C 1,500 mm THK 37 67512125
37 mm Grey Black White Black 0/120 °C 2,000 mm THK 37 67512135
40 mm White Black White Black 0/120 °C 500 mm THK 40 67652105
40 mm White Black White Black 0/120 °C 1,000 mm THK 40 67652115
40 mm White Black White Black 0/120 °C 1,500 mm THK 40 67652125
40 mm White Black White Black 0/120 °C 2,000 mm THK 40 67652135
45 x 45 mm Black White Black White 0/120 °C 500 mm THK 45 67522105
45 x 45 mm Black White Black White 0/120 °C 1,000 mm THK 45 67522115
45 x 45 mm Black White Black White 0/120 °C 1,500 mm THK 45 67522125
45 x 45 mm Black White Black White 0/120 °C 2,000 mm THK 45 67522135
52 mm Grey Black White Black White 0/120 °C 500 mm THK 52 67502105
52 mm Grey Black White Black White 0/120 °C 1,000 mm THK 52 67502115
52 mm Grey Black White Black White 0/120 °C 1,500 mm THK 52 67502125
52 mm Grey Black White Black White 0/120 °C 2,000 mm THK 52 67502135
58 x 25 mm Black Black White 0/120 °C 1,000 mm THK 150/58 S 67542115
58 x 25 mm Black Black White 0/120 °C 1,500 mm THK 150/58 S 67542125
58 x 25 mm Black Black White 0/120 °C 2,000 mm THK 150/58 S 67542135
58 x 25 mm Black Black White 0/120 °C 3,500 mm THK 150/58 S 67542155

Blue part no. = in-stock items

Description Format Language Download / Link
Data sheet Thermometers THK With capillary tube Data sheet PDF
AFRISO Data sheet Thermometers THK With capillary tube
Nominal size
37 – 40 – 52
45 x 45 – 58 x 25
Range
0/120 °C
Accuracy/test point
50 °C = ± 3 °C
Measuring principle
Liquid filling
Operating temperature range
Medium:
Full scale value
Ambient:
Max. 70 °C
Operating pressure
Without pressure
Degree of protection
IP 32 (EN 60529)

Standard design

Connection
Probe:
∅ 6 x 30 mm, ∅ 6.5 x 30 mm, Copper
Capillary tube:
Copper with PVC coating (R3, grey)
Dial
Plastic, white or black
Scaling black or white
Pointer
Plastic, black or white
Black or white
Housing
Plastic (ABS), grey, white or black
Window
Plastic, clipped in
Bezel
Plastic (ABS), black
THK 52:
Push on bezel
Capillary length
500, 1,000, 1,500, 2,000, 3,500 mm

Options

  • Dial with customer logo
  • Various capillary lengths
  • Special colours for housing, dial, pointer
Type THK 37
Type THK 37
AFRISO
Dimensions (in mm)
  1. Capillary length
Type THK 40
Type THK 40
AFRISO
Dimensions (in mm)
  1. Capillary length
Type THK 45
Type THK 45
AFRISO
Dimensions (in mm)
  1. Capillary length
Type THK 52
Type THK 52
AFRISO
Dimensions (in mm)
  1. Capillary length
