New Products

Benefits

• For machine and plant engineering
• Extremely robust plastic housing (PA 6.6 GB30)
• Laminated safety glass window
• Higher accuracy class optional

Application

For gaseous and liquid media which are not highly viscous, do not crystallise and do not attack copper alloys. For high measuring accuracy.

! For measuring gas or vapour, observe the table "Selection Criteria as per EN 837-2"

Benefits

• Robust stainless steel housing
• High-precision measurements with integrated transducer
• Mechanical, power-independent local display
• Zero calibration via magnet

Application

For pressure measurements with a power-independent local display in combination with an electrical output signal.

Benefits

• Easy adjustment via magnetic pin
• Degree of protection IP 68 with fixed cable connection
• For tank heights of 100 mm and more
• EX version suitable for mining

Application

Capacitance level indicator with 2-wire or 3-wire technology for continuous level measurement of liquids and bulk solids (flour, sand, cement, plastic granules) in open and closed container, tanks or silos. Particularly suitable for low tank heights.

Benefits

• Non-contact level measurement
• Easy adjustment even without medium
• Robust housing for rough ambient conditions
• Suppression of interference signals

Application

For continuous, non-contact level measurement in open or closed containers, tanks or silos. Suitable for liquid, mushy and pasty media. Ideal for sludge, adhesives, resins and waste water. The device can be easily adjusted even without a medium by means of the programming display with user-friendly menus. It also serves as a local display.

Benefits

• Level measurement independent of changes in pressure, temperature or density
• Stable, reliable measurement even with foam, vapour, dust or turbulent surfaces of the medium
• Robust housing for rough ambient conditions
• Maintenance-free, not subject to wear and tear

Application

For universal continuous level measurement in containers, tanks or silos. Suitable for liquid, powdery, electrically conductive or non-conductive media. Ideal fro changing media. FEP-coated and PFAcoated probes are available for corrosive, highly clean media or food. Also suitable for pressurised or vacuum tanks. The device can be easily adjusted by means of the programming display with user-friendly menus; it also serves as a local display.

Benefits

• Easy adjustment via magnetic pin
• IP 68 degree of protection
• For temperatures of the medium of up to 300 °C
• EX version suitable for mining

Application

For level detection of conductive and non-conductive liquids in tanks, ducts, pipes or silos. Particularly suitable for application in the food, pharmaceutical and chemical industries. Also ideal for level detection of bulk solids such as sand, gravel, cement and granular material stored in open or closed containers.

Benefits

• Optical measuring principle for fast, accurate measurement results and real time diagnostics
• Reliable measurement results, not influenced by interference (e.g. shocks)
• Intuitive operation via menu-guided measuring sequences
• Operation, flue gas analysis and data output via the optional flue gas analyser MULTILYZER STx as central controller
• Withdrawal system with quick-action coupling lock
• Visualisation via 5.7" colour touch display
• Permanent indication of the current measured value
• Output of the mass concentration of dust as a 15 minute mean value
• Qualification-tested also for 30-minutes mean value measurement
• Short setup time due to fast heat-up and zero point phase
• Easy connection of flue gas analyser MULTILYZER STx via Bluetooth^®
• Compact, robust measuring system

Application

Dust measuring instrument specially designed for mobile use at solid-fuel systems such as pellets or wood fired systems for determining the mass concentration of particles/dust and for monitoring the limit values for particulate matter. Approved for stages 1 and 2, including limit value monitoring 150 mg/m³ for old systems as well as 30-minutes mean value measurement (single-stage measurement) of single room combustion systems. The sampling probe can also be used for tightness tests of the entire gas path. Ideal for chimney sweeps, heating system engineers and service technicians for performing required particulate matter measurements, e.g. as per 1st German Federal Immission Act.

Benefits

• Automatic sensor regeneration via fresh air valve allows for convenient long-term measurements of up to 12 hours
• Optionally with humidity sensor for sensor protection
• Smart system protection by means of continuous monitoring of fresh air valve, heated line, cooler and humidity sensor
• Particularly suitable for industrial applications due to the robust, light.weight design (7.5 kg)
• Large range of probes:
• - Heated line including draft and flue gas temperature
• - modular probe system
• - High-temperature probes
• Automatic zero point for convenient and fast measurement preparation

Application

Gas treatment system specially for mobile applications. Whenever high-precision gas analysis is required where the flue gas may contain pollution and condensate, MAXISYSTEM ST is the system of choice. In the analysis of highly water-soluble gases such as NO₂ and SO₂, MAXISYSTEM ST must be used in order to be able to obtain reliable measurement results. The modular measurement concept allows to use the corresponding flue gas analyser MULTILYZER STx as a "stand-alone device" or in conjunction with MAXISYSTEM ST. With the integrated temperature controller, the temperature of the heated line can be optimally adjusted to the application between 100 °C and 180 °C. Flue gas analysis, draft/differential pressure and flue gas temperature are directly measured. Efficiency, flue gas loss and dew point are calculated in real time. The operating state of the measuring device can be checked via the status indication of the heated line and the gas cooler. The condensate outlet integrated in the housing reliably discharges condensate. MAXISYSTEM ST is designed for quasi-continuous operation with an operating time of up to 12 hours.

Benefits

• Fast and reliable detection of flammable gases
• Sensor for a wide range of flammable gases (base calibration: methane)
• Sensor protection for long service life
• Flexible gas probe for use in spaces difficult to access
• Audible alarm if limit values are exceeded

Application

For detection of gas leaks (flammable gases) in gas pipes as well as connection pieces and fittings, gas meters, gas burners and gas tanks. The intensity of the escaping gas is indicated by the three LEDs. At the same time, the instrument generates an audible signal whose frequency is proportional to the gas concentration. Preset limit values.

Benefits

• Universal for numerous CAPBs^® sensor modules without use of additional apps
• Large TFT colour display for live indication of measured values
• Ergonomic handle made of robust, high-quality plastic with three integrated magnet for hands-free operation
• Ideal for simple measurement programs such as pressure drop test, gas leak measurement, differential pressure measurement
• Data transmission via QR code to AFRISO apps for creation of comprehensive measurement records
• Charging during measurements thanks to mains connection via interface module

Benefits

• Measurement of anodes installed in an isolated way
• Check and assessment of current anode status
• Works with base handle BG 10 or CAPBs^® device (not scope of delivery)
• Can be used in conjunction with AFRISO BlueLine measuring instruments, smartphones or tablets as evaluation units
• Easy and fast documentation of the measured value via the applet "Anode Test" in the app EuroSoft^® live
• Create comprehensive PDF report with notes, photos and signature and share it via e-mail or messenger

Benefits

• Verification and documentation of thermal disinfection and the temperature profile in conjunction with the AFRISO TOOLBOX app
• Documentation of water exchange as a part of the intended operation of drinking water installations in conjunction with the AFRISO TOOLBOX app
• Inspection of thermostatic mixing valves
• Acceptance tests of newly installed drinking water installations
• Function tests of circulation lines

Application

• Verification and documentation of thermal disinfection and the temperature profile in conjunction with the AFRISO TOOLBOX app
• Documentation of water exchange as a part of the intended operation of drinking water installations in conjunction with the AFRISO TOOLBOX app
• Function checks of decentralised drinking water heaters
• Checking the output capacity of heat exchangers
• Function tests of circulation lines
• Inspection of fittings (minimum volume flow)
• Determination of the water temperature at water taps
• Inspection of thermostatic mixing valves
• Acceptance tests of newly installed drinking water installations

Application

• CO₂ concentration measurement and professional assessment of ambient air quality in rooms
• Adjustment of ventilation and air conditioning systems as per EN 16798 (formerly EN 13779) or TRGS 900 (limit values for workplaces)
• Sampling tests at workplaces in offices and production facilities, in laboratories, in storage areas, in greenhouses
• Testing of stationary CO₂ measuring instruments

Benefits

• Set for pressure tests as per BTGA und DIN EN 1264-4 of underfloor systems for heating and cooling
• Test media water or air
• Test adapter (G¾ female) for direct connection to the manifold system
• Standardised quick-action coupling system for easy test setup
• Can be modularly extended for DPK 60 sens series
• Pressure transmitter PT 70 (0/25 bar)
• Easy test and PDF documentation via applet "Tightness test" in the EuroSoft^® live app

Application

• Tightness tests at underfloor systems for heating and cooling
• For liquid, gaseous and corrosive media

Benefits

• Checking and assessing the drinking water quality
• Assessing the system water in heating systems, for example, heating system water analysis as per VDI 2035
• Modular extension kit for fast on-site analysis of the water quality like laboratory analyses
• Multi-purpose sensor for pH value, electrical conductivity, German hardness, salinity and temperature
• With titrating solution for °dH for chemically treated water or water softened by means of ion exchange
• Robust, modular system case M, suitable for box and shelf system Sortimo-Boxx
• Can be used in conjunction with AFRISO BlueLine measuring instruments, smartphones or tablets as evaluation units
• Easy and fast documentation of measured values by means of evaluation app EuroSoft live or BlueLine measuring instrument
• Professional PDF measurement report with the following parameters: total hardness, conductivity and pH value as per new German VDI 2035

Application

• Measurement of pH value, electrical conductivity, salinity and temperature
• Determination of German hardness and the TDS value (total dissolved solids in mg/l)

Benefits

• Set for performing hydraulic balancing with the AFRISO valve ranges VarioQ and Vario-DP directly at the radiator
• Measurement and check of differential pressure and flow rate
• Can be used in conjunction with AFRISO BlueLine measuring instruments, smartphones and tablets as evaluation units
• Robust, modular system case M , suitable for box and shelf system Sortimo-Boxx
• Step by step measurements in conjunction with the app EuroSoft^® live
• Quickly create PDF documentation with signatures, photographs and additional notes and send them via smartphone or tablet
• With the app AFRISO TOOLBOX: VdZ-compliant design, documentation and confirmation of hydraulic balancing according to "Procedure A"

Application

• For differential pressure measurement and flow rate adjustment in heating and refrigerating systems during hydraulic balancing
• To be used in conjunction with VarioQ and Vario-DP thermostat valves, lockshield valves and combination blocks during hydraulic balancing directly at the radiator. It is neither necessary to know the pipeline system nor to perform complex calculations.

Benefits

• Set for performing hydraulic balancing at line fittings and line control valves
• Measurement and check of differential pressure and flow rate
• Can be used in conjunction with AFRISO BlueLine measuring instruments, smartphones and tablets as evaluation units
• Robust, modular system case M , suitable for box and shelf system Sortimo-Boxx
• Step by step measurements in conjunction with the app EuroSoft^® live
• Quickly create PDF documentation with signatures, photographs and additional notes and send them via smartphone or tablet

Application

• For differential pressure measurement and flow rate adjustment at line fittings and line valves during hydraulic balancing
• Can be used with all standard valves from all standard manufacturers
