3-Wege-Mischventil ARV Vario | 1338520

in-stock items

for distribution and mixing
3-way mixing valve with adjustable flow coefficient Kvs
low torque for increased service life of actuator
ProClick adapter system for motor mounting without tools

Universal mixing application in water-based heating and cooling systems (radiators, surface heating systems), also suitable as distribution or zone manifold. Suitable for water and water/glycol mixtures with up to 50 % glycol. Not suitable for drinking water.

Compact, low-loss 3-way mixing valves with brass base and easy-to-handle rotary knob made of high-strength plastic. The rotary knob with scale allows for easy and accurate manual adjustment of the mixing valve. The elevated mark allows for fast position determination. Two scales with "0 to 10" for horizontal installation and "10 to 0" for vertical installation are included for maximum flexibility.
3-way mixing valve for distribution and mixing. The precise mixing ratio of hot boiler water and cold water from the return line ensures the desired flow temperature.
The mixing valves are easy to automate with the AFRISO actuators. The new AFRISO ProClick adapter system allows for hassle-free mounting of the motor to the mixing valve without tools – snap on and done. The low torque ensures a low load and a long service life.

Angle of rotation: 90 °

Operating temperature range

Medium:: 5/95 °C

Nominal pressure: max. 10 bar

Differential pressure: max. 1 bar

Flow rate: see ordering table

Leak rate (∆p = 100 kPa)

: DN 32 – DN 50: < 0.7 % Kvs

Material

Housing:: brass (CW617N)

O rings:: EPDM
