TV 22 GL | 53701

Isolation amplifier

manufactured goods

The TV 22 GL isolation amplifier is used for galvanic isolation and amplification of DC signals (mA).

Input and output are galvanically isolated with a high degree of isolation. The integrated high-efficiency electronic power supply unit helps to avoid overheating and allows for high output loads. The extremely narrow design results in a high packing factor.

Housing

: DIN rail housing

W x H x D:: 18 x 78 x 103 mm

Supply voltage

: AC/DC 20 − 253 V

Input: 0–20 mA oder 4–20 mA

Output

: 0–20 mA oder 4–20 mA

: 1:1 to input signal

Output load

: max. 400 Ohm
